The available drawings are presently being restaurated and digitilized, an example of the first drawings is shown below, the rest will follow soon.

The blueprints are not for sale, but members of the VINTAGE GLIDING CLUB

can have a copy of the drawings in the archive at cost for their personel use.

I would appreciate to find the missing original drawings for installation of Shempp-Hirth airbrake system, installation for winch hook  and installation of the wheel brake system. Original drawing numbers, 7,14,23,26,28,29,32 and 43

If you want more information about the building plans of the Minimoa there is a CD for sale at the glider museum Wasserkuppe

https://www.segelflugmuseum.de/

Mail: kontakt@segelflugmuseum.de

Color scheme
